Super durable polyester powder coatings

Location: China
Business Type: Manufacturer, Exporter
Brands: Huacai
Certificate: ACS,NSF,QUALICAOT,WRAS,KTW
Model: RAL COLOR
Terms of payment and delivery: 30% Pre-payment,70% before delivery
Minimum order quantity: 100kg
Price: Consultation
Packing details: 20kg/ctn
Delivery time: 7-10DAYS
Payment method: T/T,L/C
E-mail : [email protected]
















BRIEF

This series of products is based on Dehe and Jji Juxi Road and IGIC chemical agent as the main base.It is designed for theexternal materials of the company and has excellent weather resistance.It has 10-15 years of weather resistance.Sex.



PRODUCT SERIES

Plane away from light, flat bacteria flat light, flat painting light.sand pattern, wrinkle grave recommended: Some products are certified by Qvalicoat Closs2.



REFERENCE STANDARD

AAMA2604-98《HIGH PERFORMANCE ORGANIC COATINGS ON ALUMINUM EXTRUSIONS AND PANEL5》



FILM PROPERTIES

Mechanical

behavior

Pencil
hardness
GB/T6739-1996 >H
Adhesion GB/T9286-1998 Level0
Bending GB6742-86 φ3mm
Shock GB/T1732-93 50kg.cm
Cup burst GB 9753-88 >6mm

Corrosion

resistance

Resistant
mortar
GB/T1594 GBT178, GB5237.4
no significant change
Salt spray
resistance
GB/T1771-91 There was no change in the coating film for 1000 hours, and the single-sided corrosion at the cross-section was(2
mm.
This experiment uses Minghua aluminum plate with a coating thickness of 100um.
Heat and humidity
\resistance
GB/T1740-79 1000 hours of film loss of light
<1 level
Weather
resistance
EN20105-A02 ≥4

Note: The above parameters are laboratory data and are for reference only. The actual indicators are related to the customer's environment, equipment, substrate, pre-treatment, spraying process and other factors.



APPLICATION CONDITION

Pre-treatment: phosphating treatment, enlightenment treatment: painting: suitable for the following equipment coating: high-pressure electrostatic spraying, friction electrostatic spraying, electrostatic fluidized bed spraying, fluidized bed dip coating. Curing conditions:1400C @ 30 minutes,1800C@15
minutes,200·C@10 minutes, can also be designed according to customer needs. package Packed in carton, net weight 20kg/carton, lined with polyethylene plastic bag.



PACKAGE

Net weight 20kg/carton,lined with polyethylene plastic bag



STORAGE CONDITIONS

Store in a dry, ventilated room below 30 C, avoid direct sunlight.Under these conditions, the powder can be stored stably for 6 months.



SAFE AND HEALTHY

All raw materials of powder coating do not contain toxic substances, and will not release toxic gases during baking.
Avoid inhaling dust during use. Operators should wear dust masks and minimize long-term contact between skin and powder. The paint on the skin can be cleaned with a fertilizer house.

about us huacai

Zhejiang Huacai Advanced Material CO., LTD is an outdoor powder coating manufacturer and electrostatic powder coating paints supplier. Our factory was established in 1998, covers an area of 30 thousand square meters. The company is located in Huzhou, Zhejiang. Guangdong Huacai Powder Technology CO., LTD was established in 2016, located in Dongwan, Guangdong. We’re the top ten manufacturers that produce indoor, outdoor powder coating and electrostatic powder coating paint in China. HUACAI regards product quality as the life of the enterprise, We strictly control the quality of products, in addition to own resin factory, we use advanced testing instruments(SHIMADZU XRF, Mastersizer 3000E, Datacolor 400) to test products.
